Applicable to medical and health services, scientific research, agricultural and other units, to the medical equipment, dressings, glassware, solution culture medium to carry out sterilization, also is a necessary test equipment food factory, drinking water plant to do QS, HACCP certification.
| Quantity: | |
|---|---|
BKQ-B50II, BKQ-B75II, BKQ-B100II, BKQ-B120II, BKQ-B150II, BKQ-B200II
BIOBASE
Application range:
There are 5 fixed programs and 2 DIY programs according to different sterilization objects such as dressings, equipment, tools, rubber, liquid, culture medium, waste, etc.
Safety Features:
* Over pressure. Safety valve can automatically open to release pressure.
* Over temperature. The system will power off automatically.
* Door sensor. Sensor at door closing position, to check the door status. If door is open, operation will stop.
* Anti-dry out function. If water level is too low, system will power off and error code displays on screen.
* Over current. Over voltage or electric leakage protection apparatus-air switch.
* Door cover. The door is covered with safety shell made of thermal insulation material, which can protect operator from burning by heat and looks nice.
Technical Features:
* Water inlet filter to keep high water quality(except BKQ-B150/200II).
* Optional printer for recording sterilization data.
* LED screen displays all steps of full process as well as error codes.
* Independent quick service window, easy for repairing and maintenance.
* Automatic selecting quick or low exhaust to avoid sterilization liquid overflowing.
* Sterilization programs for dressings, equipment, rubber, culture medium, waste, etc.
* Hand wheel type of quick-open door structure, self-expandable sealing ring, easy operating and safe.
* Complete process of filling water, dynamic pulse exhaust, heating, sterilizing, draining and drying runs automatically.
* Adopting certain temperature(98~102℃) exhaust method and dynamic pulse exhaust method to empty the cold air inside chamber for ensuring steam saturability.
* Inner stainless steel water tank for water and steam to circulate inside. Steam dose not exhaust during sterilization, so as to keep the outside clean and dry(except BKQ-B150/200II).
* Drying function (except BKQ-B150/200II)
* Optional stainless steel bucket and tray(except BKQ-B150/200II).
* Standard 1 pc stainless steel tray(except BKQ-B150/200II).
Models:
| Model | BKQ-B50II | BKQ-B75II | BKQ-B100II | BKQ-B120II | BKQ-B150(II) | BKQ-B200(II) |
| Capacity | 50L | 75L | 100L | 120L | 150L | 200L |
| Chamber Size(mm) | φ386*514 | φ386*695 | φ386*875 | φ386*1055 | φ500*760 | φ500*1000 |
| Chamber Material | S30408 | |||||
| Designed Pressure | 0.28Mpa | 0.217Mpa | ||||
| Designed Temp | 134℃ | 138℃ | ||||
| Working Pressure | 0.23MPa | 0.217MPa | ||||
| Working Temp. | 105~136℃ | 50~134℃ | ||||
| Temp. Display Accuracy | 0.1℃ | |||||
| Timing Range | 0~999min | 0~99h | ||||
| Dynamic Pulse Exhaust Times | 0~9 times | / | ||||
| Dynamic Pulse Exhaust Temp. | 105~136℃ | |||||
| Temp. Holding Range | 45~60℃ | 50~100℃(programmable) | ||||
| Consumption | 4.4KW | 4.7KW | 5.2KW | 5.2KW | 6KW | |
| Power Supply | AC110/220V±10%, 50/60Hz | 380V, 50Hz/200V, 50/60Hz | ||||
| SS Basket | 1 pc | 2pcs | 2pcs | 3pcs | 3 pcs | 4pcs |
| External Size(W*D*H)mm | 640*550*970 | 640*550*1080 | 640*550*1280 | 640*550*1380 | 650*650*1400 | 650*650*1700 |
| Package Size(W*D*H)mm | 750*745*1100 | 750*745*1240 | 750*745*1450 | 750*745*1540 | 800*760*1530 | 800*760*1720 |
| Gross Weight(kg) | 102 | 112 | 125 | 140 | 213 | 238 |
Note: It is applicable to the altitude below 3,000m
