BH-QNY01 BH-QNY02
BIOBASE
Features:
1. Built-in 10.1-inch touch screen, built-in thermal printer.
2. Sample delivery, injection, droplet, analysis and report output are completed automatically by the instrument.
3. High-precision sample dispenser is used to ensure thorough reaction and improve the accuracy of test results.
4. Automatic strip selection chamber, accommodating 600 test strips at the same time.
5. Supports closed puncture analysis, greatly improving biosafety.
Technical Parameters:
Model | BH-QNY01 | BH-QNY02 |
Principle | Photoelectric colorimetry | |
Throughput | 240 tests/hour | |
Screen | 10.1-inch touch screen | |
Memory | Can store more than 1,000,000 test reports | |
Printer | Built-in thermal printer | |
Interface | USB, RS232, network interface | |
Barcode Scanner | Can be optional | |
Range of Application | 9, 10, 11, 14 test strip | |
Items | 9 Test strip: GLU, BIL, KET, pH, BLD, PRO, URO, NIT, LEU 10 Test strip: GLU, BIL, KET, SG, pH, BLD, PRO, URO, NIT, LEU 11 Test strip: GLU, BIL, KET, SG, pH, BLD, PRO, URO, NIT, LEU, VC; 14 Test strip: GLU, BIL, KET, SG, pH, BLD, PRO, URO, NIT, LEU, VC, CRE, CAL, MCA. | |
Sample Rack Capacity | 100pcs samples (10pcs test tube racks) | |
Reagent Tank Capacity | 600pcs | |
Data Retrieval | Can be searched by actual date, range date, urine sample number, name, barcode, etc. | |
Automatic Sensing | Automatically detects and analyzes after placing the sample | |
Calibration Function | Yes | |
Power | 130W | |
Power Supply | AC100-240V, 50/60Hz | |
External Size(W*D*H) | 662*730*520mm | 662*780*520mm |
Net Weight | 48kg | 51.5kg |
Packing Size(W*D*H) | 805*880*600mm | 805*880*600mm |
Gross Weight | 76.5kg | 80kg |
Remark: The machine comes standard with 100 test strips.
Features:
1. Built-in 10.1-inch touch screen, built-in thermal printer.
2. Sample delivery, injection, droplet, analysis and report output are completed automatically by the instrument.
3. High-precision sample dispenser is used to ensure thorough reaction and improve the accuracy of test results.
4. Automatic strip selection chamber, accommodating 600 test strips at the same time.
5. Supports closed puncture analysis, greatly improving biosafety.
Technical Parameters:
Model | BH-QNY01 | BH-QNY02 |
Principle | Photoelectric colorimetry | |
Throughput | 240 tests/hour | |
Screen | 10.1-inch touch screen | |
Memory | Can store more than 1,000,000 test reports | |
Printer | Built-in thermal printer | |
Interface | USB, RS232, network interface | |
Barcode Scanner | Can be optional | |
Range of Application | 9, 10, 11, 14 test strip | |
Items | 9 Test strip: GLU, BIL, KET, pH, BLD, PRO, URO, NIT, LEU 10 Test strip: GLU, BIL, KET, SG, pH, BLD, PRO, URO, NIT, LEU 11 Test strip: GLU, BIL, KET, SG, pH, BLD, PRO, URO, NIT, LEU, VC; 14 Test strip: GLU, BIL, KET, SG, pH, BLD, PRO, URO, NIT, LEU, VC, CRE, CAL, MCA. | |
Sample Rack Capacity | 100pcs samples (10pcs test tube racks) | |
Reagent Tank Capacity | 600pcs | |
Data Retrieval | Can be searched by actual date, range date, urine sample number, name, barcode, etc. | |
Automatic Sensing | Automatically detects and analyzes after placing the sample | |
Calibration Function | Yes | |
Power | 130W | |
Power Supply | AC100-240V, 50/60Hz | |
External Size(W*D*H) | 662*730*520mm | 662*780*520mm |
Net Weight | 48kg | 51.5kg |
Packing Size(W*D*H) | 805*880*600mm | 805*880*600mm |
Gross Weight | 76.5kg | 80kg |
Remark: The machine comes standard with 100 test strips.
