BH-NY01S
BIOBASE
Application Places:
Hospitals, scientific research institutions, maternity and child hospitals, community clinics, etc.
Features:
1. The product is small and light, easy to carry, and suitable for detection needs in different scenarios.
2. Automatic detection, intelligent identification, can detect up to 14 items.
3. 4.3-inch touch screen, menu-based operation interface, easy to operate.
4. High-brightness cold light source, long service life.
5. System upgrade function, users can experience the latest software support simultaneously.
Technical Parameters:
Model | BH-NY01 |
Principle | Computer vision detection technology |
Throughput | 700 tests/hour |
Screen | 7-inch touch screen |
Memory | Can store more than 37000 test reports |
Printer | Built-in thermal printer |
| Interface | USB, RS232, LIS proposal |
| Barcode Scanner | Can be optional |
Range of Application | 9, 10, 11, 14 test strip |
Items | 9 test strip: GLU, BIL, KET, PH, BLO, PRO, URO, NIT, LEU 11 test strip: GLU, BIL, KET, SG, PH, BLO, PRO, URO, NIT, LEU, VC |
Power Supply | 100~240V, 50/60Hz |
| External Size(W*D*H) | 346*320*206mm |
Net Weight | 4kg |
| Package Size(W*D*H) | 425*385*305mm |
| Gross Weight | 8kg |
Remark: The machine comes standard with 10 test strips.
