| Quantity: | |
|---|---|
BBR-4V626 BBR-4V966
BIOBASE
Features:
1. Multiple sensors design: make sure the precise monitoring and programming.
2. Electric heated glass semi-foamed door, easy to observe, also keep a better cooling temperature.
3. Forced air refrigeration system, ensure inner temperature constant and uniform.
4. Adjustable shelves, improve space utilization; blood storage baskets can be classified.
5. Individual transparent inner door, effectively reduce cool air loss when opening the door.
Technical Parameters:
Model | BBR-4V626 | BBR-4V966 | |
Capacity | 626L | 966L | |
Temp. Range | 2~6℃ | ||
Temp. Accuracy | 0.1℃ | ||
Temp. Uniformity | ≤1.5℃ | ||
Temp. Stability | ≤2℃ | ||
Recovery Time(Recover to 6℃ in an ambient temp. of 32℃) | ≤15min | ||
Cooling Time(Cool down to 5℃ in an ambient temp. of 32℃) | ≤100min | ||
Control System | Microprocessor control | ||
Display | LED display | ||
Alarm | High or low temperature, sensor&system failure alarm, door ajar alarm, power failure alarm, battery switch alarm | ||
Refrigeration Type | Air-cooling | ||
Refrigerant | R134a/240g | ||
Compressor | International famous compressor/1 | ||
Condenser&Evaporator | Copper tube aluminum fin type | ||
Defrost | Automatic defrost | ||
Construction | Polyurethane cyclopentane foam | ||
Material | Internal Material | Stainless steel | |
External Material | Sprayed steel plate | ||
Door | Outer door: electrically heated glass semi-foam door*2 Inner door: acrylic door*6 | ||
Casters | Yes | ||
Consumption | 550W | 560W | |
Power Supply | AC220V, 50Hz(Standard); 110/220V,60Hz(Optional) | ||
Shelf | 12pcs | ||
Baskets | 36pcs | ||
Blood Bags(450ml) | 360pcs | 576pcs | |
Standard Accessory | Thermal printer, test hole | ||
Optional Accessory | Temperature recorder, USB interface, RS485 interface | ||
Internal Size(W*D*H) | 1100*420*1325mm | 1100*650*1325mm | |
External Size(W*D*H) | 1220*665*1885mm | 1220*895*1885mm | |
Package Size(W*D*H) | 1340*750*2100mm | 1340*980*2100mm | |
Net Weight | 220kg | 246kg | |
Gross Weight | 250kg | 286kg | |
Features:
1. Multiple sensors design: make sure the precise monitoring and programming.
2. Electric heated glass semi-foamed door, easy to observe, also keep a better cooling temperature.
3. Forced air refrigeration system, ensure inner temperature constant and uniform.
4. Adjustable shelves, improve space utilization; blood storage baskets can be classified.
5. Individual transparent inner door, effectively reduce cool air loss when opening the door.
Technical Parameters:
Model | BBR-4V626 | BBR-4V966 | |
Capacity | 626L | 966L | |
Temp. Range | 2~6℃ | ||
Temp. Accuracy | 0.1℃ | ||
Temp. Uniformity | ≤1.5℃ | ||
Temp. Stability | ≤2℃ | ||
Recovery Time(Recover to 6℃ in an ambient temp. of 32℃) | ≤15min | ||
Cooling Time(Cool down to 5℃ in an ambient temp. of 32℃) | ≤100min | ||
Control System | Microprocessor control | ||
Display | LED display | ||
Alarm | High or low temperature, sensor&system failure alarm, door ajar alarm, power failure alarm, battery switch alarm | ||
Refrigeration Type | Air-cooling | ||
Refrigerant | R134a/240g | ||
Compressor | International famous compressor/1 | ||
Condenser&Evaporator | Copper tube aluminum fin type | ||
Defrost | Automatic defrost | ||
Construction | Polyurethane cyclopentane foam | ||
Material | Internal Material | Stainless steel | |
External Material | Sprayed steel plate | ||
Door | Outer door: electrically heated glass semi-foam door*2 Inner door: acrylic door*6 | ||
Casters | Yes | ||
Consumption | 550W | 560W | |
Power Supply | AC220V, 50Hz(Standard); 110/220V,60Hz(Optional) | ||
Shelf | 12pcs | ||
Baskets | 36pcs | ||
Blood Bags(450ml) | 360pcs | 576pcs | |
Standard Accessory | Thermal printer, test hole | ||
Optional Accessory | Temperature recorder, USB interface, RS485 interface | ||
Internal Size(W*D*H) | 1100*420*1325mm | 1100*650*1325mm | |
External Size(W*D*H) | 1220*665*1885mm | 1220*895*1885mm | |
Package Size(W*D*H) | 1340*750*2100mm | 1340*980*2100mm | |
Net Weight | 220kg | 246kg | |
Gross Weight | 250kg | 286kg | |
