BK-6310VET
BIOBASE
Features:
1. Throughput 60T/H.
2. 14-inch touch screen.
3. Tri-angle laser scatter + flow cytometry method + impedance method for RBC and PLT counting.
4. 3D holographic scattergram displays the accurate 5-part differentiation of WBC.
5. Large storage capacity: 300,000 results(including histogram, scattergram, animal information).
Technical Parameters:
Model | BK-6310VET | |||
Throughput | 60 Tests/hour | |||
Sample Profile | Dog, cat, horse, sheep, goat, camel, cow, more species coming soon | |||
Assay Items | 5 parts, 29 parameters, 3 histograms, 3D scattergram | |||
Principle | Tri-angle laser scatter, Flow cytometry method, 3D scattergram analysis, Impedance method for RBC and PLT counting, Cyanide-free method for HGB test | |||
Test Mode | CBC mode, CBC+DIFF mode Venous whole blood, prediluted | |||
Sample Volume | CBC+DIFF mode: ≤20μl CBC mode: ≤10μl | |||
Parameters | WBC, RBC, HGB, HCT, MCV, MCH, MCHC, RDW-SD, RDW-CV, PLT, MPV, PCT, PDW, P-LCR, P-LCC, NEU%, LYM%, MON%, EOS%, BAS%, NEU#, LYM#, MON#, EOS#, BAS#. 4 research parameters: ALY%, ALY#, LIC%, LIC# | |||
Performance | Item | Linearity range | Carry Over | CV |
WBC | 0~300*109/L | ≤0.5% | ≤2.0% | |
RBC | 0~8.6*1012/L | ≤0.5% | ≤1.5% | |
HGB | 0~260g/L | ≤0.5% | ≤1.5% | |
PLT | 0~3000*109/L | ≤1.0% | ≤4.0% | |
Storage | 300,000 results including histograms, scattergrams and patient information | |||
Interface | 4 USB ports, 1 LAN port, Bi-direction LIS, support HL7 protocol, Internal RFID reader | |||
Power Supply | AC100-240V,50/60Hz, 300VA | |||
Package Size(W*D*H) | 575*490*690mm | |||
Gross Weight | 46kg | |||
Reagent Package Size | 330*330*330mm, 400*290*240mm, 400*290*240mm | |||
Reagent Gross Weight | 22kg 2kg, 2kg | |||
