Cube Ice Machine 60kg 220kg 550kg

Introduction:
The Cube Ice Machine is a high-efficiency commercial-grade appliance designed to produce crystal-clear, hard cube ice for use in laboratories, healthcare facilities.

Availability:

Quantity:



Inquire Add to Basket

Model:
CIM-150 CIM-200 CIM-300 CIM-800
Brand:
BIOBASE

Features:

1. Eco-friendly & Efficient: fluorine-free high-efficiency compressor with energy-saving refrigeration system.

2. Continuous Ice Production: simple structure with 4 adjustable feet for easy cleaning.

3. Hygienic & Durable: food-grade stainless steel exterior, stylish and easy to maintain.

4. Fully Automated Operation: smart control system for automatic water intake, ice-making, ice release, storage, and shutdown when full.

5. Dual Independent Cooling Systems: energy-saving design allows separate operation of each unit(Only for CIM-800).

6. Ideal for scientific research labs and seafood preservation(Only for CIM-800).

Usage Notes:

1. Water Supply: connect to tap water (0.2~0.7 MPa pressure required).

2. Ventilation Space: ≥100 mm clearance on both sides; ≥150 mm clearance at the rear.

3. Maintenance: clean the condenser every 6 months to ensure optimal cooling and longevity.

Technical Parameters:

Model	CIM-150	CIM-200	CIM-300			CIM-800
Ice Making Capacity(kg/24h)	150	200	300			800
Max. Ice Storage Capacity	60kg		220kg			550kg
Ice Shape	Cube ice: 222222mm
Way of Condensation	Air-cooling				Water-cooling
Ambient Temperature	5~40℃
Compressor	Panasonic Wanbao			GMCC
Refrigerant	R290, 0.7kg	R290, 0.8kg	R290, 0.95kg			R290, 1.1kg
Standard Accessory	Ice scoop1, water inlet hose1, drain hose1, spare sealing washer1
Consumption	720W		1200W			3200W
Power Supply	AC 220V, 50Hz(Standard); 110V, 60Hz, 220V, 60Hz(Optional)
External Size(WDH)	600670965mm		5908301580mm			12209101840mm
Package Size(WDH)	740720930mm		Main machine: 610730680mm Ice storage bin: 610930970mm			Main machine: 1270690690mm Ice storage bin: 12709601200mm
Net Weight	65kg		80kg			210kg
Gross Weight	70kg		87kg			230kg
