| Quantity: | |
|---|---|
BDF-40H105 BDF -40H205 B DF-40H305 BDF -40H485
BIOBASE
Model
| Model | BDF-40H105 | BDF-40H205 | BDF-40H305 | BDF-40H485 |
| External Size(L*W*H) mm Capacity | 680*580*935 105L | 1160*765*885 220L | 1530*765*885 320L | 1655*755*915 485L |
| Temperature Range Temperature Accuracy Control System | -10℃~-40℃ | -15°℃~-40℃ | -20℃～-40℃ | |
| 0.1℃ Microprocessor Control,LED Display | ||||
| Alarm | BDF-40H100&BDF-40H485:High or low temperature alarm, sensor failure alarm, Power failure alarm,Temperature controller failure alarm BDF-40H200&BDF-40H300:High temperature alarm,sensor failure alarm | |||
| Refrigeration Type Refrigerant Evaporator | Direct Refrigeration | |||
| R290 | R404a and R23 | R290 | ||
| Material of Copper | ||||
| Structure Internal material External material | Unibody Design & Mono-assembly foaming (Rigid polyurethane insulation material) 304 Stainless Steel Powder coated cold rolled steel plate | |||
| onsumption Power Supply | 160W | 380w | 46ow | 295W |
| AC220V±10%,50/60Hz;110V±10%,60Hz | ||||
| Package Size(L*WH)mm Gross Weight | 750*700*1040 | 1230*835*1055 | 1600*835*1055 | 1775*900*1060 |
| 65kg | 143kg | 170kg | 138kg | |
