BKB-Y-800-D BK-Y-1000-D BKB-G-1600-D
BIOBASE
Features:
1. The coexistence of man and machine means that it can be disinfected in a manned environment or in an unmanned environment.
2. LCD touch display, real-time display of indoor temperature and humidity(Humidity only for BKB-G-1600-D).
3. 6 groups of on-off time can be booked within 24 hours, wind speed can be adjusted in three gears.
4. Manual, timing, temporary and automatic working modes(Automatic working mode only for BKB-G-1600-D) are available.
5. With two-section plasma generator, the upper part uses 4000V plasma generator to adsorb dust particles, and the lower part uses 8000V plasma generator to sterilize and disinfect(Mobile type). With plasma generator, fan, negative ion module fault alarm, filter maintenance warning(BKB-G-1600-D). The service life can reach 30000 hours.
6. Built-in high-concentration negative-ion generator, release negative ions to adsorb dust particles in the air and purify the air.
7. The device has two fans and two plasma generators with large air volume and space disinfection capacity(Only for BKB-G-1600-D).
8. Filter is easy to disassemble.
Technical Parameters:
Model | BKB-Y-800-D | BK-Y-1000-D | BKB-G-1600-D |
Type | Mobile type | Floor type | |
Disinfection Type | Plasma and electrostatic adsorption | ||
Applicable Space | ≤80m3 | ≤100m3 | ≤160m3 |
Circulating Air | ≥800m3/h | ≥1000m3/h | ≥1600m3/h |
Shell Material | ABS shell | Metal shell | |
Ozone Leakage | ≤0.01mg/m³ | ≤0.033mg/m3 | ≤0.01mg/m³ |
Plasma Density | 3.40*10^17m-3~1.75*10^18m-3 | 3.49*10^17m-3~8.67*10^17m-3 | 3.38*10^17m-3~1.84*10^18m-3 |
Negative Ion Generation | ≥5*10^6pcs/cm3 | ||
Electric Field Intensity of Sterilization Area | 8000V | ||
Electric Field Intensity of Dust Accumulation Area | 4000V | ||
Natural Bacteria Extinction Rate | ≥90% | ||
Sterilization Rate of Staphylococcus Albus | ≥99.9% | ||
Noise | ≤55dB(A) | ||
Consumption | ≤100W | ≤200W | |
Power Supply | Standard: AC220V, 50/60Hz Optional: 110V, 50/60Hz | ||
External Size(W*D*H)mm | 370*360*710 | 540*410*900 | 370*360*1340 |
Package Size(W*D*H)mm | 440*430*780 | 574*481*975 | 440*430*1420 |
Net Weight(kg) | 20.5 | 23 | 41.8 |
Gross Weight(kg) | 25.3 | 28.5 | 47.7 |
