BJPX-SH23 BJPX-SH55 BJPX-SH88 BJPX-SH105 BJPX-SH140 BJPX-SH200
BIOBASE
Features:
1. The maximum temperature can reach 250 degrees Celsius to maintain the disinfection effect.
2. Precise temperature control design can accurately reach the set disinfecting temperature to ensure that the temperature does not drop.
3. It has an observable perspective window to observe the situation of the disinfected items at any time.
4. Timing system, hands free, more convenient to use.
5. Precise temperature control: The temperature control system adopts microcomputer single chip technology, and the system has functions such as temperature control, timing and over-temperature sound and light alarm.
Technical Parameters:
Model | BJPX-SH23 | BJPX-SH55 | BJPX-SH88 | BJPX-SH105 | BJPX-SH140 | BJPX-SH200 | |
Capacity | 23L | 55L | 88L | 105L | 140L | 200L | |
Circulation Mode | Forced convection | ||||||
Integrated Safety Controller(Temperature Sensor) | PT100 | ||||||
Temp. Control Range | RT+10~250℃ | ||||||
Timing Range | 0~9999 minutes | ||||||
Temp. Fluctuation | ±3℃ | ||||||
Temp. Uniformity | ±5℃ | ||||||
Ambient Temp. | 5-40℃ | ||||||
Overall Structure(Inside and Outside) | 304 stainless steel(Customized) | ||||||
Chamber Size(W*D*H) | 256*263*314mm | 356*340*414mm | 433*363*470mm | 435*457*500mm | 604*463*558mm | 605*491*658mm | |
Altitude | ＜2000m | ||||||
Shelf | 240*240mm, 2pcs, can be optional | 340*340mm, 2pcs, can be optional | 340*440mm, 2pcs, can be optional | 440*440mm, 2pcs, can be optional | 440*540mm, 2pcs, can be optional | 490*590mm, 2pcs, can be optional | |
Standard Accessories | Shelf*2 | ||||||
Optional Accessories | Shelf | ||||||
Consumption | 600W | 1000W | 1200W | 1600W | 2000W | 2300W | |
Power Supply | AC220V, 50/60Hz(Standard); AC110V, 50/60Hz(Optional) | ||||||
External Size(W*D*H) | 583*393*486mm | 683*494*586mm | 781*482*642mm | 781*593*670mm | 881*594*730mm | 931*644*802mm | |
Net Weight | 29.5kg | 42kg | 53kg | 62kg | 67.5kg | 75kg | |
Package Size(W*D*H) | 675*522*641mm | 775*622*741mm | 873*622*796mm | 873*722*825mm | 973*722*885mm | 1023*722*985mm | |
Gross Weight | 40kg | 53kg | 65kg | 78kg | 90kg | 105kg | |
