BK-C800
BIOBASE
Features:
1. 7 inches LCD touch screen display
2. Main material ≥1.2mm cold rolled steel plate, epoxy resin electrostatic spraying
3. Main door material ≥5mm acrylic plate, excellent weather and chemical resistance
4. Real-time temperature and humidity environment monitoring system, set alarm parameters, to ensure product safety.
5. Low wind speed monitoring: detect low wind speed alarm system, adjustable fan speed
6. Filter saturation alarm system: equipped with double filter and double VOC probes
7. Door alarm system: display screen alarm and buzzer alarm will appear when cabinet door is opened
Technical Parameters：
Model | BK-C800 |
External Size(mm) | 800*580*2150 |
Internal Size(mm) | 797*480*1750 |
Molecular Filter Size(mm) | 750*400*75 |
Primary Filter Size(mm) | 725*375*20 |
Air Volume(m³/h) | 200-230 |
Temperature &Humidity Alarm | 2 sets |
Power | 180W |
Storage Capacity | 160 bottles（500ml） |
Layer Qty | 8pcs |
Layer Burden | ＞70kg |
Noise | ≤63dB |
Power Supply | Standard: 220V/50Hz, optional: 110V, 60Hz (External transformer) |
Packing Size | 960*960*2200mm |
Gross Weight | 250kg |
Features:
1. 7 inches LCD touch screen display
2. Main material ≥1.2mm cold rolled steel plate, epoxy resin electrostatic spraying
3. Main door material ≥5mm acrylic plate, excellent weather and chemical resistance
4. Real-time temperature and humidity environment monitoring system, set alarm parameters, to ensure product safety.
5. Low wind speed monitoring: detect low wind speed alarm system, adjustable fan speed
6. Filter saturation alarm system: equipped with double filter and double VOC probes
7. Door alarm system: display screen alarm and buzzer alarm will appear when cabinet door is opened
Technical Parameters：
Model | BK-C800 |
External Size(mm) | 800*580*2150 |
Internal Size(mm) | 797*480*1750 |
Molecular Filter Size(mm) | 750*400*75 |
Primary Filter Size(mm) | 725*375*20 |
Air Volume(m³/h) | 200-230 |
Temperature &Humidity Alarm | 2 sets |
Power | 180W |
Storage Capacity | 160 bottles（500ml） |
Layer Qty | 8pcs |
Layer Burden | ＞70kg |
Noise | ≤63dB |
Power Supply | Standard: 220V/50Hz, optional: 110V, 60Hz (External transformer) |
Packing Size | 960*960*2200mm |
Gross Weight | 250kg |
