Dry Heat CO2 Incubator 80L 160L

Application:

The CO2 incubator is widely used in the research and production of immunology, oncology, genetics, microbiology and agricultural science, and has become one of the most commonly used conventional instruments in laboratories.

Availability:
Quantity:
  • BJPX-C80D BJPX-C160D

  • BIOBASE

Features:
1. IR infrared sensor, using dual-channel dual-filter infrared technology.

2. The inner tank is designed with semicircular corners and the surface is made of 304 mirror finish stainless steel.

3. Adopt double heating module, six side heating.

4. The cavity is uniformly heated by silicone rubber heating wire heater with aluminum foil-wrapped, offering rapid temperature rise and good uniformity.

5. Equipped with leakage current and over-voltage protectors. Features over-temperature, under-temperature, over-concentration and under-concentration alarms.


Technical Parameters:

Model

BJPX-C80D

BJPX-C160D

Type

Dry heat CO2 incubator, air jacket

Sterilization Type

140℃ dry heat sterilization

Capacity

80L

160L

Temp. Sensor

PT100

Temp. Range

5~30℃

Temp. Fluctuation

±0.3℃(@37℃)

Temp. Uniformity

±0.5℃(@37℃)

Temp. Precision

0.1℃

Timing Range

0~999h or continuous

Display

7-inch touch screen

CO2 Control

IR infrared sensor with calibration certificate

CO2 Range

0~20vol%

CO2 Uniformity

0.2vol%

CO2 Control Resolution

0.1vol%

Ambient Temperature and Humidity

Ambient Temperature: 5~30℃(Recommendation: 25±2℃)

Ambient Humidity: ≤80%

Filter

CO2 gas filter

Power Supply

Standard: AC220V, 50/60Hz

Optional: 110V, 50/60Hz(External transformer)

Wiring Method: plug

Consumption

650W(During cultivation)

1900W(During dry heat sterilization)

700W(During cultivation)

1950W(During dry heat sterilization)

Shelves

2pcs, adjustable

Standard Accessories

Shelves, USB interface, CO2 relief valve, water tank, CO2 gas filter

Optional Accessory

Three-way connector

Internal Size(W*D*H)

400*352*576mm

460*551*646mm

External Size(W*D*H)

620*596*1007mm

710*786*1107mm

Package Size(W*D*H)

720*720*1140mm

810*900*1255mm

Net Weight

90kg

110kg

Gross Weight

110kg

135kg
