BJPX-SP05 BJPX-SP08 BJPX-SP10 BJPX-SP18 BJPX-SP36
BIOBASE
Features:
1. High quality cold plate hot spray shell, flat surface, inner liner mirror 304 stainless steel laser welding, easy to clean.
2. The tray adopts mould injection molding, which solves the storage safety of platelets.
3. Three-dimensional air duct design with circulating fan, so that the equipment inside the forced air cooling temperature circulation, to ensure the uniformity of internal temperature.
4. High quality AC servo motor, smooth work, low noise, long service life.
5. Double-layer electric heating tempered glass door, good temperature insulation effect, effectively avoid the observation window fog, keep the box temperature constant for a long time.
6. The bottom is equipped with casters and support foot, easy to move, can adjust the level.(Not applicable to BJPX-SP05)
7. Using real-time digital signal monitoring, micro-processing PID control, information processing is fast.
Technical Parameters:
Model | BJPX-SP05 | BJPX-SP08 | BJPX-SP10 | BJPX-SP18 | BJPX-SP36 |
Display | 7-inch LCD touch screen | ||||
Temperature Control Range | 22.0±2.0℃ | ||||
Temperature Display Resolution | 0.1℃ | ||||
Temperature Fluctuation | ±1.0℃ | ||||
Temperature Uniformity | ±2.0℃ | ||||
Mode of Oscillation | Continuous left and right reciprocation, horizontal oscillation | ||||
Refrigerant | R134a, CFC free | ||||
Defrost | Automatic defrost | ||||
Alarm | Ultra-high and ultra-low temperature alarm, Oscillation device(motor) failure, Long-term door open alarm | ||||
Oscillation Frequency | 60±5 times/min | ||||
Oscillation Amplitude | 50±5mm | ||||
Ambient Temperature | 5~35℃ | ||||
Bags(200ml) | 1~10 | 1~16 | 1~20 | 1~36 | 1~72 |
Material | External Material: Cold plate thermal spraying Internal Material: 304 stainless steel | ||||
Consumption | 1200W | 950W | 1300W | 950W | 1500W |
Power Supply | AC220V, 50/60Hz(Standard); 110V, 50/60Hz(Optional, external transformer) | AC220V, 50/60Hz(Standard); 110V, 50/60Hz(Optional) | AC220V, 50/60Hz(Standard); 110V, 50/60Hz(Optional, external transformer) | ||
Standard Accessory | USB interface, LED lamp, UV lamp | ||||
Optional Accessory | Printer | ||||
Internal Size(L*W*H) | 500*310*460mm | 485*310*569mm | 498*450*578mm | 500*337*970mm | 1018*343*895mm |
External Size(L*W*H) | 832*610*660mm | 632*600*1225mm | 645*730*1225mm | 632*620*1600mm | 1140*612*1600mm |
Package Size | 930*710*810mm | 757*853*1375mm | 740*853*1375mm | 726*706*1755mm | 1235*706*1755mm |
Net Weight | 80kg | 110kg | 138kg | 135kg | 215kg |
Gross Weight | 95kg | 132kg | 160kg | 160kg | 255kg |
