| Quantity: | |
|---|---|
BOV-H50, BOV-H100, BOV-H226
BIOBASE
Features:
1. Outer material: cold-rolled steel plate sprayed on the surface; inner material: SUS stainless steel plate.
2. PID microprocessor temperature control, precise and reliable temperature control.
3. The inner box is designed with a circular arc structure, which is easy to clean.
4. Optional printer or RS485 interface for software connection(For BOV-H50/100).
Technical Parameters:
Model | BOV-H50 | BOV-H100 | BOV-H226 |
Capacity | 50L | 100L | 226L |
Temp. Range | RT+20~400℃ | 50~500℃ | |
Temp. Precision | 0.1℃ | ||
Temp. Fluctuation | ±0.5℃ | ±1℃ | |
Temp. Fluctuation | ±3.0% | ±3.5% | |
Timing Range | 0~5999min | 0~9999min | |
Display | LCD | LED | |
Alarm | Overtemperature alarm, temperature probe damage alarm | ||
Material | External cold-rolled steel with painting, Internal stainless steel | ||
Ambient Temp. | 5~40℃ | ||
Power Supply | AC380V, 50Hz | ||
Consumption | 3250W | 4050W | 8000W |
Shelves No. | 2 pcs | 3pcs | |
Optional Accessories | Printer/RS485/USB | / | |
Internal Size(W*D*H)mm | 350*350*400 | 450*450*450 | 602*500*753 |
External Size(W*D*H)mm | 890*700*920 | 990*790*990 | 1070*770*1122 |
Package Size(W*D*H)mm | 1010*820*1150 | 1100*920*1210 | 1150*860*1510 |
Net Weight(kg) | 153 | 180 | 174 |
Features:
1. Outer material: cold-rolled steel plate sprayed on the surface; inner material: SUS stainless steel plate.
2. PID microprocessor temperature control, precise and reliable temperature control.
3. The inner box is designed with a circular arc structure, which is easy to clean.
4. Optional printer or RS485 interface for software connection(For BOV-H50/100).
Technical Parameters:
Model | BOV-H50 | BOV-H100 | BOV-H226 |
Capacity | 50L | 100L | 226L |
Temp. Range | RT+20~400℃ | 50~500℃ | |
Temp. Precision | 0.1℃ | ||
Temp. Fluctuation | ±0.5℃ | ±1℃ | |
Temp. Fluctuation | ±3.0% | ±3.5% | |
Timing Range | 0~5999min | 0~9999min | |
Display | LCD | LED | |
Alarm | Overtemperature alarm, temperature probe damage alarm | ||
Material | External cold-rolled steel with painting, Internal stainless steel | ||
Ambient Temp. | 5~40℃ | ||
Power Supply | AC380V, 50Hz | ||
Consumption | 3250W | 4050W | 8000W |
Shelves No. | 2 pcs | 3pcs | |
Optional Accessories | Printer/RS485/USB | / | |
Internal Size(W*D*H)mm | 350*350*400 | 450*450*450 | 602*500*753 |
External Size(W*D*H)mm | 890*700*920 | 990*790*990 | 1070*770*1122 |
Package Size(W*D*H)mm | 1010*820*1150 | 1100*920*1210 | 1150*860*1510 |
Net Weight(kg) | 153 | 180 | 174 |
