BJPX-1102X, BJPX-2102X
BIOBASE
Features:
* Audio and visual alarm.
* Power off recovery function.
* High efficiency servo motor, accurate control speed.
* Super low speed start, start speed adjustable, overspeed automatic protection.
* Accessories: Monitor timer(standard accessories); Open the door automatically stop, UV disinfection function, humidity shaker, high temperature shaker(optional accessories).
Models:
Model | BJPX-1102X | BJPX-2102X |
Controller | PID | |
Display | LCD | |
Circulation Mode | Forced convection | |
Shaking Mode | Rotary shaking | |
Drive Mode | Multidimensional drive | |
Rotating Speed | 20~350rpm(Can do static culture, positive and negative) | |
Rotating Accuracy | ±1rpm | |
Vibration Range | Φ26mm, (Can customize φ35(20-250rpm/min), φ50(20-200rpm/min)) | |
Temp. Range | RT+5~60℃ | 4~65℃(At 25℃) |
Temp. Accuracy | ±0.1℃ | |
Temp. Uniformity | ±0.5℃(At 37℃) | |
Timing Range | 0~9999h/min | |
Shaking Plate Size | 710*455mm | |
Shaking Plate Quantity | 2pcs | |
Max. Capacity | 100ml*100 or 250ml*56 or 500ml*44 or 1000ml*24(Flask clamp) | |
Standard Capacity | 250ml*28, 500ml*22 | |
Internal Material | Stainless steel | |
External Material | Stainless steel | |
Refrigerant | / | R134A |
Cooling Consumption | / | 250W |
Heating Consumption | 700W | |
| Audio and visual alarm for over-temperature; | |
Consumption | 900W | 1150W |
Power Supply | 220V±10%,50/60Hz(Standard); 110V±10%, 60Hz(Optional) | 220V±10%, 50Hz(Standard); 110V±10%, 50Hz(Optional) |
Internal Size(W*D*H)(mm) | 840*530*600 | |
External Size(W*D*H)(mm) | 950*700*1280mm | |
Package Size(W*D*H)(mm) | 1100*850*1500mm | |
Gross Weight(kg) | 270 | 290 |
