BJPX-L200BK BJPX-L200BKII
BIOBASE
Features:
1. The incubator is designed with circular arc structure for easy cleaning.
2. LED light plate cold light source lighting, irradiation surface more uniform, less heat, making the box temperature more stable.
3. The illumination grade is adjustable, it can be adjusted by controlling the on and off of different light lines to simulate day and night
4. Large screen LCD display, multiple groups of data display in one screen, menu type operation interface, simple and easy to understand, easy to operate;
5. The operation interface has automatic lock function to ensure the safety of operation
6. Imported compressor, CFC-free refrigerant,eco-friendly and highly efficient.
7. Pull-out movable shelf, adjustable spacing, equipped with casters, easy to move.
8. Non-slip off shelf design, prevent the petri dish slip, more secure.
9. Small front door design, both thermal insulation and can prevent the loss of light.(BJPX-L200BK)
10. There is a door on the front, left and right, and each door has lamp tubes(BJPX-L200BKII)
Technical Parameters:
Model | BJPX-L200BK | BJPX-L200BKII |
Capacity | 200L | |
Temperature Control Range | With illumination: 10~60℃; Without illumination: 0~60℃ | |
Temperature Display Resolution | 0.1℃ | |
Temperature Fluctuation | ±0.5℃ | |
Temperature Uniformity | ±1.0℃ | |
Ambient Temperature | 5~30℃, 25±2℃ is recommended | |
Timing Range | 0~9999min/h or continuous | |
Temperature Controller | PID controller, 30-segment program | |
Display | LCD display | |
Lighting Type | Top lighting | Three-sided illumination |
Intensity of Illumination | Top vertical LED cold light source: 0~20000lx | Three side(left, right and front) LED cold light source: 0~20000lx |
Illumination Adjustment Grade | 10-grade adjustable | 5-grade adjustable |
Refrigerant | R134a/250g | |
Circulation Mode | Forced convection | |
Alarm | Independent temperature limit alarm system, leakage current and over voltage protector, Over-temperature alarm(＞2℃) | |
Material | External material: cold rolled steel; Internal material: 304 stainless steel | |
Power Supply | Standard: AC220V±10%, 50/60Hz Optional: AC110V±10%, 50/60Hz | |
Consumption | 1200W | |
Shelves | 521*435mm, 2pcs(one with LED cold light source, one without), can be optional | 515*435mm, 2pcs, can be optional |
Standard Accessories | Shelf*2, Mechanical lock | |
Optional Accessories | Shelf, Test port, RS485 interface, USB interface, Printer(USB must also be optional) | |
Internal Size(W*D*H)mm | 548*476*778 | 548*476*778 |
External Size(W*D*H)mm | 750*760*1500 | 750*760*1530 |
Package Size(W*D*H)mm | 870*885*1700 | 870*885*1700 |
Net Weight(kg) | 135 | 175 |
Gross Weight(kg) | 160 | 200 |
Features:
1. The incubator is designed with circular arc structure for easy cleaning.
2. LED light plate cold light source lighting, irradiation surface more uniform, less heat, making the box temperature more stable.
3. The illumination grade is adjustable, it can be adjusted by controlling the on and off of different light lines to simulate day and night
4. Large screen LCD display, multiple groups of data display in one screen, menu type operation interface, simple and easy to understand, easy to operate;
5. The operation interface has automatic lock function to ensure the safety of operation
6. Imported compressor, CFC-free refrigerant,eco-friendly and highly efficient.
7. Pull-out movable shelf, adjustable spacing, equipped with casters, easy to move.
8. Non-slip off shelf design, prevent the petri dish slip, more secure.
9. Small front door design, both thermal insulation and can prevent the loss of light.(BJPX-L200BK)
10. There is a door on the front, left and right, and each door has lamp tubes(BJPX-L200BKII)
Technical Parameters:
Model | BJPX-L200BK | BJPX-L200BKII |
Capacity | 200L | |
Temperature Control Range | With illumination: 10~60℃; Without illumination: 0~60℃ | |
Temperature Display Resolution | 0.1℃ | |
Temperature Fluctuation | ±0.5℃ | |
Temperature Uniformity | ±1.0℃ | |
Ambient Temperature | 5~30℃, 25±2℃ is recommended | |
Timing Range | 0~9999min/h or continuous | |
Temperature Controller | PID controller, 30-segment program | |
Display | LCD display | |
Lighting Type | Top lighting | Three-sided illumination |
Intensity of Illumination | Top vertical LED cold light source: 0~20000lx | Three side(left, right and front) LED cold light source: 0~20000lx |
Illumination Adjustment Grade | 10-grade adjustable | 5-grade adjustable |
Refrigerant | R134a/250g | |
Circulation Mode | Forced convection | |
Alarm | Independent temperature limit alarm system, leakage current and over voltage protector, Over-temperature alarm(＞2℃) | |
Material | External material: cold rolled steel; Internal material: 304 stainless steel | |
Power Supply | Standard: AC220V±10%, 50/60Hz Optional: AC110V±10%, 50/60Hz | |
Consumption | 1200W | |
Shelves | 521*435mm, 2pcs(one with LED cold light source, one without), can be optional | 515*435mm, 2pcs, can be optional |
Standard Accessories | Shelf*2, Mechanical lock | |
Optional Accessories | Shelf, Test port, RS485 interface, USB interface, Printer(USB must also be optional) | |
Internal Size(W*D*H)mm | 548*476*778 | 548*476*778 |
External Size(W*D*H)mm | 750*760*1500 | 750*760*1530 |
Package Size(W*D*H)mm | 870*885*1700 | 870*885*1700 |
Net Weight(kg) | 135 | 175 |
Gross Weight(kg) | 160 | 200 |
