Introduction:
This equipment provide a long-time stable environment of temperature, humidity and illumination. It's applied in the growth test, high humidity test and high illuminance test.
| Quantity: | |
|---|---|
BJPX-MS120A, BJPX-MS288A, BJPX-MS500A
BIOBASE
Features:
1. The shell is sprayed steel plate, the inner chamber is made of 304 stainless steel, full arc design, convenient for cleaning and maintenance.
2. Using SECOP refrigeration compressor, high efficiency, low consumption; non-fluorine environmentally friendly refrigerant.
3. Microcomputer intelligent PID temperature and humidity controller, accurate temperature control, with parameter memory function, automatically resume operation after restoring electricity.
4. Automatically disconnects power to the humidifier heater when no humidification water is available.
5. Over-temperature alarm, under-temperature alarm, temperature probe damage alarm, humidity probe damage alarm.
6. Temperature and humidity real-time curve display and 600-day historical data query function; 600-day historical data USB export function; ethernet-based remote monitoring function.
Technical Parameters:
Model | BJPX-MS120A | BJPX-MS288A | BJPX-MS500A |
Sterilization Type(Optional) | UV sterilization | ||
Capacity | 173L | 288L | 516L |
Temp. Range | -20~65℃ | ||
Temp. Fluctuation | ±0.5℃ | ||
Temp. Precision | 0.1℃ | ||
Humidity Range | 40~95%RH | ||
Humidity Fluctuation | 3%RH | ||
Illumination | Single-side illumination 4500Lux, 4-level adjustable | ||
Refrigeration System | R404a refrigerant, CFC-free | ||
Timing Range | The timer can be set for a maximum of 99 hours for a single step, with a total of 100 steps available | ||
Display | 7-inch touch screen | ||
Power Supply | Standard: AC220V, 50/60Hz(Standard) Optional: 110V, 50/60Hz(External transformer) | ||
Consumption | 2100W | 2600W | 3500W |
Shelves | 3pcs, adjustable | ||
Standard Accessories | Shelves, LED lamp, φ35mm test hole, built-in water tank, automatic water replenishment interface, USB port, PC port | ||
Optional Accessories | Miniature thermal printer or miniature pin printer, external temperature protection device, external temperature and humidity SMS alarm module | ||
Internal Size(W*D*H)mm | 500*450*700 | 600*600*800 | 800*710*910 |
External Size(W*D*H)mm | 830*660*1590 | 980*760*1610 | 1090*960*1820 |
Package Size(W*D*H)mm | 920*750*1740 | 1080*860*1860 | 1190*1070*1970 |
Net Weight(kg) | 158 | 195 | 253 |
Gross Weight(kg) | 187 | 230 | 298 |
